Data sheet

Phase

Three phase

Maximum power three phase (KW)

40

Continuous power three phase (KW)

36

Maximum power three phase (KVA)

50

Continuous power three phase (KVA)

45

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

PERKINS 1103A-33TG1, turbocharged

Emissions Regulations

Stationary Use

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3300

Number cylinders

3

Cylinders' position

In line

Cooling

Water

Alternator

Mecc Alte

Poles

4

Fuel tank capacity (L)

100

Consumption (L/h)

8.2 at 75% of the load

Running time (h)

12 at 75% of the load

Acoustic pressure

60 dB(A) at 7 m

Length (mm)

2100

Width (mm)

870

Height (mm)

1165

Dry weight (Kg)

1020

Silenced

Yes

Super silenced

Yes

Product type

Generator

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins

Precision of voltage regulation

± 1%
