GENSET MGF 16 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 16 KVA
MGF 16 Y
Maximum power Three-phase: 16 KVA
Maximum power Three-phase: 12.8 KW
Maximum power Single phase: 5.3 KVA
Maximum power Single-phase: 4.24 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 3TNV88 (STAGE V)
Starting: Electric
Consumption: 2.7 Lt/h
Length: 1430 mm
Width: 690 mm
Height: 930 mm
Weight: 470 Kg
Super silenced
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 4.24
- Maximum power single phase (KVA)
- 5.3
- Maximum power three phase (KW)
- 12.8
- Maximum power three phase (KVA)
- 16
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A CEE - 1 x 400V 32A CEE - 2 x 230V 16A CEE
- Engine
- Yanmar 3TNV88, 4 stroke
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 1642
- Number cylinders
- 3
- Cooling
- Water
- Alternator
- Synchronous
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 40
- Consumption (L/h)
- 2.7
- Running time (h)
- 14.81
- Acoustic power
- 96 dB(A)
- Acoustic pressure
- 71 dB(A) at 7 m
- Length (mm)
- 1430
- Width (mm)
- 690
- Height (mm)
- 930
- Dry weight (Kg)
- 470
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR (optional)
- Engine manufacturer
- Yanmar
- Brand
-
GENSET MGF 16 Y
The GENSET MGF 16 Y is a single-phase/three-phase 16 KVA diesel generator with electric start.
Thanks to its compact size and its very low weight, the GENSET MGF 16 Y is a light and easy to transport generator.
The GENSET MGF 16 Y also has a low fuel consumption: only 2.7 Lt/h at 75% of the load.
The GENSET MGF 16 Y generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
