      MG 6020 DM

      Phase type: Single-phase
      Maximum single-phase power: 7.5 KVA / 6 KW
      Engine: Kubota Z 482
      Engine speed: 3000 rpm
      Emissions standard: Stage V
      No. Cylinders: 2
      Cooling: Air
      Displacement: 479 cm3
      Power: 11.1 HP (8.3 kWm)
      Starter: Electric
      Fuel: Diesel
      Voltage: 230 V
      Frequency: 50 Hz
      Fuel consumption 75%: 2.6 Lt/h
      Acoustic pressure: 87 (62 dB at 7 m)
      Length: 941 mm
      Width: 550 mm
      Height: 600 mm
      Dry weight: 190 kg

      Custom Quote
      Product: GENSET MG 6020 DM - VEHICULAR GENERATOR 7.5 KVA

      PERSONAL DATA


      Ask a question
      Product: GENSET MG 6020 DM - VEHICULAR GENERATOR 7.5 KVA
      Offer on letterhead
      Product: GENSET MG 6020 DM - VEHICULAR GENERATOR 7.5 KVA
      GENSET
      MG 6020 DM

      Data sheet

      Phase
      Single phase
      Maximum power single phase (KW)
      6
      Maximum power single phase (KVA)
      7.5
      Fuel
      Diesel
      Frequency (Hz)
      50
      Voltage (V)
      230
      Engine
      KUBOTA Z482
      Emissions Regulations
      Stage 5
      Engine rpm (rpm)
      3000
      Starting system
      Electric
      Engine capacity (cm³)
      479
      Number cylinders
      2
      Cooling
      Air
      Alternator
      Synchronous
      Protection degree
      IP23
      Motor insulation class
      H
      Consumption (L/h)
      2.6 at 75% of the load
      Acoustic power
      87 dB(A)
      Acoustic pressure
      62 dB(A) at 7 m
      Length (mm)
      941
      Width (mm)
      550
      Height (mm)
      600
      Dry weight (Kg)
      190
      Silenced
      Yes
      Super silenced
      Yes
      Product type
      Generator
      ATS Switch device
      No
      Voltage regulator
      No
      Engine manufacturer
      Kubota

      Specific References

      New

      GENSET MG6020DM VEHICULAR GENERATOR 7.5KVA

      The GENSET MG6020DM 7.5KVA Vehicular Generator represents an excellent choice in
      the world of Vehicle-Mounted Generators, designed for those who require reliability,
      power, and quiet operation in a single device. This GENSET MG6020DM StageV has
      been specifically engineered for installation on special vehicles, such as service trucks,
      motorhomes, trucks, caravans, and Civil Protection rescue vehicles.
      The GENSET MG6020DM combines high performance with a compact and lightweight
      structure, making it the ideal solution for any mobile requirement.

      Main Features of the GENSET MG6020DM:

      Nominal Power: 7.5 kVA
      Engine: Kubota 3000 RPM, compliant with Stage V standards
      Power Supply Type: Single-phase
      Control System: Remote control panel
      Muffler: Integrated for optimal noise reduction

      The GENSET MG6020DM has been developed to offer efficient and smooth operation
      under all conditions. With a nominal power of 7.5 kVA, this Vehicular Generator is
      capable of providing reliable energy to a wide range of electrical equipment, ensuring
      operational continuity in any situation. The Kubota engine, known for its reliability and
      durability, operates at 3000 RPM, fully complying with StageV regulations for
      low environmental impact.

      One of the main advantages of the GENSET MG6020DM is its exceptional quietness.
      Thanks to the integrated muffler, the generator maintains an extremely low sound
      power level of only 87 Lwa. This makes it ideal for use in contexts where acoustic
      comfort is essential, such as in recreational vehicles and rescue vehicles, ensuring a
      quiet and disturbance-free environment.

      The GENSET MG6020DM is equipped with a practical remote control panel, allowing for
      simple and safe management of the generator directly from inside the vehicle. The
      compact dimensions of 941 x 550 x 600 mm and the contained weight of 190 kg make
      installation easy without compromising the available space on the vehicle.
      This GENSET MG6020DM Vehicular Generator is the perfect solution for those who need
      a powerful generator that is also easily integrable into any vehicle configuration.

      Detailed Technical Specifications GENSET Vehicular Generator:

      Nominal Power: 7.5 kVA
      Power Supply Type: Single-phase
      Engine: Kubota, 3000 RPM, Stage V
      Sound Power Level: 87 Lwa
      Weight: 190 kg
      Dimensions (L x W x H): 941 x 550 x 600 mm
      Control System: Remote control panel
      Muffler: Integrated for noise reduction

      Are you looking for a vehicle-mounted generator with different technical specifications? HERE to explore the area dedicated to GENSET generators or other specialized brands.
