GENSET MHS 6200 H/SA INTERNAL MUFFLER

The GENSET MHS 6200 H/SA Internal Muffler is a high-quality vehicle-mounted generator designed
to provide reliable and continuous power in mobile and industrial applications.
This GENSET MHS 6200 H/SA, known for its efficiency and versatility, stands out due to several key
technical features that make it ideal for a wide range of professional uses.

One of the most distinctive aspects of the GENSET MHS 6200 H/SA Internal Muffler is its without tank
configuration, which offers greater flexibility in installation and integration with existing
fuel systems. This feature allows for optimized use of available space and customization of the
power system according to the user's specific needs.

The GENSET MHS 6200 H/SA is equipped with an internal muffler, which significantly reduces noise
levels during operation. With a sound pressure level of 83 dB (58 dB at 7 meters), it is particularly
suitable for use in noise-sensitive environments, while ensuring maximum comfort for the operator.

As a vehicle-mounted generator, the GENSET MHS 6200 H/SA Internal Muffler is designed to be
installed on commercial vehicles, trucks, and other mobile platforms. Its robustness and reliability
make it the ideal choice for those who need continuous and safe power during transport or at
temporary work sites.

Main Technical Specifications of GENSET MHS 6200 H/SA Internal Muffler:

Phase Type: Single-Phase
Maximum Single-Phase Power: 6.2 KVA / 4.96 KW
Engine: GX 390 OHV
Engine Speed: 3000 rpm
Emission Standard: Stage V
Number of Cylinders: 1
Cooling: Air
Displacement: 390 cm³
Engine Power: 11 hp (8.2 kWm)
Starting System: Electric
Fuel Type: Gasoline
Voltage: 230 V
Frequency: 50 Hz
Fuel Consumption at 75% Load: 3.3 Lt/h

The version With an integrated tank offers a capacity of 17 liters and a total weight ranging between
140 kg and 150 kg, depending on the configuration. The compact dimensions of the generator, with
a length of 831 mm, a width of 513 mm, and a height of 465 mm, make it easy to install on
various types of vehicles and mobile structures.

Are you looking for a vehicle-mounted generator with different technical specifications? HERE to explore the area dedicated to GENSET generators or other specialized brands.

Images and technical data are not binding.
