Self-priming Motor Pump Idrofoglia ZL80-1/2T-SP
ZL80-1/2T-SP
Pump type: Self-priming motor pump
Manufacturer: LOMBARDINI - KOHLER
Model: 15 LD 440
Emissions regulations: TIER 1
Power supply: Diesel
No. of cylinders: 1
Displacement: 442 cm³
Maximum debris diameter: 25x22 mm
Suction: Natural
Cooling: Air
Continuous power @ 1750 rpm: 4.0 kW - 5.4 HP
Continuous power @ 2500 rpm: 6.0 kW - 8.2 HP
Continuous power @ 3000 rpm: 6.7 kW - 9.1 HP
Maximum power @ 3600 rpm: 7.3 kW - 9.9 HP
Starting: recoil start manual
- Fuel
- Diesel
- Engine
- Lombardini 15 LD 440
- Emissions Regulations
- Stationary Use
- Starting system
- Pull starter
- Engine capacity (cm³)
- 442
- Number cylinders
- 1
- Cooling
- Air
- Pump type
- High flow rate pump
- Fluid type
- Slightly sandy wastewaters
- Height of suction (m)
- 40
- Maximum output capacity (Lt/min)
- 1600
- Max power (KW)
- 7.3
- Main body material
- Ghisa
- Inlet diameter thread type (mm/inches)
- 80 mm - 3"
- Outlet diameter thread type (mm/inches)
- 80 mm - 3"
- Mechanical power (hp)
- 9,9 Max
- Product type
- Pompa
- Brand
-
Self-priming motor-pump ZL80-1/2T-SP
Idrofoglia ZL80-1/2T-SP motor-pump with Lombardini 15LD440 diesel engine, complete with 2 spherical fittings of Ferrari type diameter 80 mm (1 delivery and 1 suction).
The motor pump Idrofoglia ZL80-1/2T-SP has a maximum flow rate of 1600 liters per minute at head 0, also allows the passage of solid debris of diameter 22x25 mm.
Self-priming Idrofoglia ZL80-1/2T-SP motor-pump with 3" - Ø80 mm inlets, performance as shown in the curve below, solids passage Ø max 25x22 mm.
Pump body: grey cast iron EN GJL 250 - Volute: spheroidal cast iron EN GJL 400 - Impeller: spheroidal cast iron EN GJL 400 - Shaft: steel C40
Painted frame on 2 wheels, with handle for manual movement. Standard tank incorporated on motor.
Manual recoil start.
Technical Characteristics Idrofoglia ZL80-1/2T-SP motor pump
Pump type: Self-priming motor pump
Manufacturer: LOMBARDINI - KOHLER
Model: 15 LD 440
Emissions regulations: TIER 1
Power supply: Diesel
No. of cylinders: 1
Displacement: 442 cm³
Maximum flow rate: 1600 litres per minute
Maximum debris diameter: 25x22 mm
Suction: Natural
Cooling: Air
Continuous power @ 1750 rpm: 4.0 kW - 5.4 HP
Continuous power @ 2500 rpm: 6.0 kW - 8.2 HP
Continuous power @ 3000 rpm: 6.7 kW - 9.1 HP
Maximum power @ 3600 rpm: 7.3 kW - 9.9 HP
Starting: recoil start manual
non-binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
