TELWIN DYNAMIC 520 START 230V 12-24V
829383
DISCONTINUED PRODUCT
Phase Type: Single-phase
Mains voltage Single-phase: 230 V
Frequency: 50 / 60 Hz
Charging power: 1.6 KW
Starting power: 10 KW
Charging voltage: 12 / 24 V
Effective charging current: 75 A
Charging current EN60335-2-29: 50 A
Current approx. 1v/c EN60335-2-29: 300 A
Maximum starting current: 400 A
Nom.ref.min. capacity: 20 Ah
Max. nominal ref. capacity: 1000 Ah
Adjustment positions: 4
Length: 36.5 cm
Width: 46 cm
Height: 75.5 cm
Weight: 20 Kg
- Phase
- Single phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 230
- Power (W)
- 10000
- Effective current (A)
- Adjustment positions
- 4
- Charging voltage (V)
- 12 / 24
- Length (mm)
- 365
- Width (mm)
- 460
- Height (mm)
- 750
- Dry weight (Kg)
- Overload protectors
- Yes
- EAN13
- 800489773285
- Brand
-
DYNAMIC 520 START 230V 12-24V
cod. 829383
Battery charger and starter for charging free electrolyte batteries (WET) with 12/24V voltage and starting all kinds of cars, vans and light trucks.
Features:
- choice of normal charge, quick charge (BOOST), quick start
- display of charging and starting current
- protection against overloads and polarity reversal.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
