LINZ SLS18 MD Single-phase alternator 18 kVA 60 Hz with AVR
      LINZ SLS18 MD Single-phase alternator 18 kVA 60 Hz with AVR
      LINZ SLS18 MD Single-phase alternator 18 kVA 60 Hz with AVR

      LINZ SLS18 MD Single-phase alternator 18 kVA 60 Hz with AVR

      SLS18 MD 60 Hz SAE3 d6.5

      Rated power at 60 Hz (kVA): 18
      Rated power factor: 1
      Rated temperature (°C): 40
      Control system: self-excited
      Design: brushless
      Type of regulation: capacitor
      Insulation class: H
      Protection: IP23
      1500 rpm
      Maximum excess travel speed (rpm): 2250
      110% overload of rated power for one hour in a 6-hour cycle
      Airflow requirement (m3/min): 5.7 at 60 Hz
      Suppression standard R.F.F.I. EN55011
      With damping cage and external cable extension

      List price
      2,398.52 € tax incl.
      1,966.00 € tax excl.
      Discounted Price
      1,927.71 € tax incl.
      1,580.09 € tax excl.
      Choose the type of coupling :
      Download PDF
      Custom Quote

      PERSONAL DATA


      Ask a question

      I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

      Offer on letterhead
      LINZ ELECTRIC
      SLS18 MD 60 Hz SAE3 d6.5

      Data sheet

      Phase
      Single phase
      Continuous power single phase (KW)
      18
      Continuous power single phase (KVA)
      18
      Frequency (Hz)
      60
      Voltage (V)
      220 / 230 / 240
      Engine rpm (rpm)
      1800
      Alternator
      Synchronous, brushless
      Poles
      4
      Single-phase power (KVA)
      18
      Protection degree
      IP23
      Motor insulation class
      H
      Length (mm)
      370
      Width (mm)
      450
      Height (mm)
      450
      Brushes
      No
      Type of alternator
      Constant Speed
      Voltage regulator
      AVR
      Weight (Kg)
      115

      Specific References

      New

      The alternators of the SLS series are single-phase 4-pole, brushless, equipped with electronic regulator (AVR).

      CHARACTERISTICS

      • Compact and mechnically resistant
      • Excellent wave form
      • Minimum maintenance
      • High efficiency
      • Type: Single-phase alternators
      • Poles: 4
      • Phases: Single-phase
      • Regulation: AVR
      • Application: INDUSTRIAL, TELECOMMUNICATION

      * Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
