LINZ SLS18 MD Single-phase alternator 15 kVA 50 Hz with AVR
SLS18 MD 50 Hz SAE3 d6.5
Rated power at 50 Hz (kVA): 15
Rated power factor: 1
Rated temperature (°C): 40
Control system: self-excited
Design: brushless
Type of regulation: capacitor
Insulation class: H
Protection: IP23
1500 rpm
Maximum excess travel speed (rpm): 2250
110% overload of rated power for one hour in a 6-hour cycle
Airflow requirement (m3/min): 5.5 at 50 Hz
Suppression standard R.F.F.I. EN55011
- Phase
- Single phase
- Continuous power single phase (KW)
- 15
- Continuous power single phase (KVA)
- 15
- Frequency (Hz)
- 50
- Voltage (V)
- 220 / 230 / 240
- Engine rpm (rpm)
- 1500
- Alternator
- Synchronous, brushless
- Poles
- 4
- Single-phase power (KVA)
- 15
- Protection degree
- IP23
- Motor insulation class
- H
- Length (mm)
- 370
- Width (mm)
- 450
- Height (mm)
- 450
- Brushes
- No
- Type of alternator
- Constant Speed
- Voltage regulator
- AVR
- Weight (Kg)
- 115
- Brand
-
The alternators of the SLS series are single-phase 4-pole, brushless, equipped with electronic regulator (AVR).
CHARACTERISTICS
- Compact and mechnically resistant
- Excellent wave form
- Minimum maintenance
- High efficiency
- Type: Single-phase alternators
- Poles: 4
- Phases: Single-phase
- Regulation: AVR
- Application: INDUSTRIAL, TELECOMMUNICATION
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
