Whisper Power Autotransformer 120/240 VAC | 100 A
61224100
Circuit Breaker Protection: 100 A bipolar
Maximum Current Passing: 100A @ 240V
Input/Output Voltage: 120V / 240V
Input/Output Frequency: Only 60 Hz
Maximum Neutral Current: 30 A continuous
Soft-Start Feature: NO
Cooling: Forced air cooling with controlled temperature
Audible Noise: Maximum sound level: < 53 dB(A)
Transformer Temperature Class: Class F (100K)
Transformer Insulation Class: Class B (130°C)
No-load Consumption: 77mA
Voltage Regulation: < 5%
Weight: < 9kg
Dimensions (H x W x D): Dimensions: 432.3 x 213 x 128 mm
- Frequency (Hz)
- 60
- Cooling
- Air
- Product dimensions (mm)
- 432,3 x 213 x 128
- Acoustic pressure
- 53 dB(A)
- Weight (Kg)
- 9
- Input/output voltage 120V / 240V
- 120V / 240V
- Brand
-
Circuit Breaker Protection: 100 A bipolar
Maximum Current Passing: 100A @ 240V
Input/Output Voltage: 120V / 240V
Input/Output Frequency: Only 60 Hz
Maximum Neutral Current: 30 A continuous
Soft-Start Feature: NO
Cooling: Forced air cooling with controlled temperature
Audible Noise: Maximum sound level: < 53 dB(A)
Transformer Temperature Class: Class F (100K)
Transformer Insulation Class: Class B (130°C)
No-load Consumption: 77mA
Voltage Regulation: < 5%
Weight: < 9kg
Dimensions (H x W x D): Dimensions: 432.3 x 213 x 128 mm
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
