-35mm input cables² L=2m
-n.1 4P B125A general switch with release coil
-n.1 relay; adjustable differential with toroid
-n.1 3P+N+E 400Vac 125A IP67 socket protected by main differential switch
-n.1 3P+N+E 400Vac 32A IP67 socket protected by 4P C32A switch
-n.2 sockets 1P+N+E 230Vac 16A IP67 protected by switch 1P+N C16A
-n.1 schuko socket IP67 protected by switch 1P+N C16A
Casing composition: ABS IP 65
Length: 460 mm
Width: 450 mm
Height: 160 mm
Weight: 15 kg
-35mm input cables² L=2m
-n.1 4P B125A general switch with release coil
-n.1 relay; adjustable differential with toroid
-n.1 3P+N+E 400Vac 125A IP67 socket protected by main differential switch
-n.1 3P+N+E 400Vac 32A IP67 socket protected by 4P C32A switch
-n.2 sockets 1P+N+E 230Vac 16A IP67 protected by switch 1P+N C16A
-n.1 schuko socket IP67 protected by switch 1P+N C16A
Casing composition: ABS IP 65
Length: 460 mm
Width: 450 mm
Height: 160 mm
Weight: 15 kg
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
