GENMAC AUTOMATIC TRANSFER SWITCH ATS-L4520 2P 50Hz 1PH 230V 72A
34795-KIT-M
Generator power singlephase: 17 KW
Protection degree: IP65
Length: 180 mm
Width: 350 mm
Height: 450 mm
Weight: 21 Kg
- Protection degree
- IP65
- Length (mm)
- 180
- Width (mm)
- Height (mm)
- 450
- Product type
- Switching Frame
- Weight (Kg)
- 21
- Brand
-
STANDARD EQUIPMENT INCLUDED:
- IP55 metal case for indoor or outdoor installation, grey colour RAL 7035
- AMFcontroller C-4520, sensing and reading the 3 phases
- selector key to power on/off and to force the load on the generator - audible warning device
- emergency stop button
- genset/mains changeover swiches mechanically and electrically interblocked
- current trasformers - terminal board for auxiliary connections
- terminal board for power load connections
- protection fuses - 10 pin connector interface to the generator
- rubber fairlead for cable inlet
- instruction manual and connection wiring diagram
- plates for wall mounting.
Not binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
