ZIPWAKE DU-S DISTRIBUTION UNIT WITH POWER CABLE 4 MT.
2011239
Supply voltage: 12 - 32 V DC
Power consumption: 0.1 W max
Protection fuse: 10 A ATO
Power cable Length: 4 m (13 ft), Diameter 9 mm (0.35 in), 12 AWG
Operating temperature: -20° to +85°C (-4° to +185°F)
Storage temperature: -40° to +90°C (-40° to +194°F)
Waterproof rating: IP67 with cables and/or protective caps mounted
Oil resistance: Common engine fluids
Compliance CE, FCC, SAEJ1171 Ignition Protected
Weight: 1.0 kg (2.2 lbs) including the power cable
- Frequency (Hz)
- 50
- Voltage (V)
- 12-32
- Protection degree
- IP 67
- Power cable length (m)
- 4
- Operating temperature (°C)
- -20 / +85
- Product type
- Electronics and Automation
- Video
- -E1WngJGVcg
- Brand
-
ZIPWAKE DU-S DISTRIBUTION UNIT
The Distribution Unit supplies the system with power and can accommodate up to six
Series S interceptors.
The unit is connected to the main control panel.
It is robust, waterproof, oil resistant and ignition protected for mounting in an
engine room.
The power cable is included for easy connection to a battery.
The distribution unit has built-in electrical protection, including its own protection fuse.
CONNECTORS
• Six interceptor connections
• I-BUS OUT (power and CAN bus to control panels)
• 2-lead power cable
• Included in Kit Boxes
• Available as accessory
• Available as spare part
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
