LINZ ELECTRIC

1 CEE 5p. socket (16A - 400V) + 1 Schuko socket + 3 poles mgt. (with IP65 cover) + voltmeter + breaker (from 11.5 kVA) fixed on top cover. Not binding images and data.

1 CEE 5p. socket (16A - 400V) + 1 Schuko socket + 3 poles mgt. (with IP65 cover) + voltmeter + breaker (from 11.5 kVA) fixed on top cover. Not binding images and data.

LINZ AEV: 1 CEE socket (32A - 230V) + 1 CEE socket (16A - 230V) + 2 poles mgt. + earth leak. br. (with IP 65 cover) + 1 breaker + voltmeter. Not binding images and data.

1 CEE 5p. socket (16A - 400V) + 1 CEE socket (16A-230V) + 3 poles mgt. (with IP65 cover) + voltmeter + breaker (from 11.5 kVA) fixed on top cover. Not binding images and data.

LINZ Impregnation for Marine Environment I7. Not binding images and data.

LINZ Device for parallel operations - PRO22 PRO28.

LINZ PT100 thermal protection for bearings.

1 CEE 5p. socket (16A - 400V) + 1 CEE socket (16A - 230V) + 3 poles mgt. (with IP65 cover) + 4p. earth leakage breaker (with IP65 cover) + voltmeter + breaker (from 11.5 kVA) fixed on top cover. Not binding images and data.

1 CEE 5p. socket (32A - 400V) + 1 CEE socket (16A - 230V) + breaker + 4p. mgt. + IP 65 cover (for mgt.) + voltmeter fixed on top cover. Not binding images and data.

Rated Power at 50Hz (kVA): 1,7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,85 at 50Hz<br...

Rated Power at 60Hz (kVA): 2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,85 at 60Hz R.F.I....

Rated Power at 50Hz (kVA): 2.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,80 at 50Hz<br...

Rated Power at 60Hz (kVA): 2.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,80 at 60Hz<br...

Rated Power at 50Hz (kVA): 2.6 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,80 at 50Hz<br...

Rated Power at 60Hz (kVA): 3.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,80 at 60Hz<br...

Power supply voltage input: a) 110 Vac ±15% b) 220 Vac -25%/+15%. Max field current: 10 Adc Permanent field current: 7 Adc Single-phase reference voltage input: 90 Vac ÷ 440 Vac Alternator output voltage calibration with multi-turn trimmer Stability control calibration with multi-turn trimmer Calibration of the intervention threshold of the low...

Rated Power at 50Hz (kVA): 3 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,75 at 50Hz R.F.I....

Rated Power at 60Hz (kVA): 3.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,7 at 60Hz R.F.I....

1 CEE 5p. socket (16A - 400V) + 1 CEE socket (16A - 230V) + 3 poles mgt. (with IP65 cover) + 4p. earth leakage breaker (with IP65 cover) + voltmeter + breaker (from 11.5 kVA) fixed on top cover. Not binding images and data.

Rated Power at 50Hz (kVA): 3.5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,75 at 50Hz<br...

Rated Power at 60Hz (kVA): 3.7 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,7 at 60Hz R.F.I....

Polybutadiene compound. Suitable for LINZ PRO28 alternators.

Rated Power at 60Hz (kVA): 5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,6 at 60Hz R.F.I....

Rated power at 50Hz (kVA): 2.2 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 3.80 at 50Hz<br...

Rated power at 60Hz (kVA): 2.7 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.80 at 60Hz<br...

Rated Power at 50Hz (kVA): 5 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,7 at 50Hz R.F.I....

Rated Power at 60Hz (kVA): 6 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 4,6 at 60Hz R.F.I....

Rated power at 50Hz (kVA): 3 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 3.75 at 50Hz<br...

Rated power at 60Hz (kVA): 3.7 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.7 at 60Hz<br...

1 CEE 5p. socket (16A - 400 V for E1X13S/2 e 32A - 400 V for E1X13M/2 )+ 1 CEE socket (16A - 230V) + 3p. mgt. + 2p. mgt. + IP65 cover (for mgt.) + voltmeter and frequencymeter (72 x72) + amperometer (72 x 72) fixed on top steel cover. Not binding images and data.

Rated Power at 50Hz (kVA): 4.2 Rated Power Factor: 1 Nominal Temperature (°C)/ 40 Control System: self-excited Execution| brushless Regulation Type: capacitor Insulation Class: H Protection: IP21 Maximum Over speed (rpm): 4500 Overload 110% of rated power for one hour in a cycle of 6 hours Air Flow Requirement (m3/min) 3,7 at 50Hz R.F.I....

Rated power at 50Hz (kVA): 3.5 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 3.75 at 50Hz<br...

Rated power at 60Hz (kVA): 4.3 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.7 at 60Hz<br...

Rated power at 50Hz (kVA): 4.2 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 3.7 at 50Hz<br...

Rated power at 60Hz (kVA): 5 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.6 at 60Hz<br...

Input voltage: 160-280V AC Output voltage: 230V AC +/- 2% Output frequency: 50Hz +/- 0.5Hz Maximum output current : 30A Efficiency: &gt;98% Operating temperature: -20°C to +50°C Protection class: IP21

Polybutadiene compound. Suitable for LINZ PRO35 alternators.

Rated power at 50Hz (kVA): 5 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.8 at 50Hz<br...

Rated power at 60Hz (kVA): 6 Rated power factor: 1 Rated temperature (°C): 40 Control system: self-excited Design: brushless Type of regulation: capacitor Insulation class: H Protection: IP21 Maximum excess travel speed (rpm): 4500 110% overload of rated power for one hour in a 6-hour cycle Airflow requirement (m3/min): 4.6 at 60Hz<br...
