MARINE GENERATORS

Phase Type: Single Phase Maximum Power: 10.5 KVA / 10.5 KW Factor cos φ: 1 Fuel: Diesel Voltage: 230 - 240 V Frequency: 50 - 60 Hz Motor: Kubota Z722, 4 Stroke Mechanical Power: 16. 6 Hp Displacement: 719 cc Engine speed: 2100 ÷ 3150 rpm Sound pressure: 54 dB(A) @ 7 m Alternator: Permanent magnets (PMG) Consumption: 3.1 l/h @ 75...

Phase Type: Single Phase Maximum Power: 12 KVA / 12 KW Factor cos φ: 1 Fuel: Diesel Voltage: 230 - 240 V Frequency: 50 - 60 Hz Motor: Kubota Z902, 4 Stroke Mechanical Power: 18 Hp Displacement: 898 cc Engine RPM: 2100 ÷ 3150 rpm Sound Pressure: 54 dB(A) @ 7 m Alternator: Permanent Magnets (PMG) Consumption: 3. 6 l/h @ 75 %<br...

Maximum power single-phase: 3.2 KW Single-phase continuous use power: 2.9 KW Fuel: Diesel Voltage: 240 V Frequency: 60 Hz Engine: Yanmar L70N Length: 593.4 mm Width: 407 mm Height: 515 mm Weight: 96 Kg

Maximum power Single-phase: 6.1 KW Single-phase continuous use power: 5.6 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Kubota Z482 Length: 650 mm Width: 468 mm Height: 555 mm Weight: 165 Kg

Maximum power single-phase: 3 KW Single-phase continuous use power: 2.7 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Yanmar L70N Length: 593.4 mm Width: 407 mm Height: 515 mm Weight: 96 Kg

Maximum power Single-phase: 5 KW Power continuous use Single-phase: 4.2 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Yanmar L100N Length: 675 mm Width: 468 mm Height: 565 mm Weight: 130 Kg

Phase Type: Single Phase Maximum Power: 5.5 KVA / 5.5 KW Continuous Power: 4.8 KVA / 4.8 KW Cos φ Factor: 1 Fuel: Diesel Voltage: 120 - 240 V Frequency: 60 Hz Motor: Yanmar L100V, 4 Stroke Emission Standard: not emitted Mechanical Power: 9. 1 Hp Displacement: 435 cc Engine speed: 3600 rpm Fuel consumption at full load: 2.5 l/h<br...

OUT OF PRODUCTION Phase Type: Single Phase Maximum Power: 5.5 KVA / 5.5 KW Continuous Power: 4.8 KVA / 4.8 KW Cos φ Factor: 1 Fuel: Diesel Voltage: 120 - 240 V Frequency: 60 Hz Motor: Yanmar L100V, 4 Stroke Emission Standard: EPA Mechanical Power: 9. 1 Hp Displacement: 435 cc Engine speed: 3600 rpm Fuel...

Phase Type: Single Phase Maximum Power: 6 KVA / 6 KW Factor cos φ: 1 Fuel: Diesel Voltage: 230 - 240 V Frequency: 50 - 60 Hz Motor: Kubota Z482, 4 Stroke Mechanical Power: 11. 1 Hp Displacement: 479 cc Engine speed: 2100 ÷ 3150 rpm Sound pressure: 72 dB(A) @ 1 m Alternator: Permanent magnets (PMG) Consumption: 2.6 l/h @ 75 %<br...

Phase Type: Single-phase Maximum Power: 7,1 KVA / 7,1 KW Continuous Power: 6,6 KVA / 6,6 KW Cos φ Factor: 1 Fuel: Diesel Voltage: 120 - 240 V Frequency: 60 Hz Engine: Kubota, 4 Stroke Emission Regulation: EPA Tier III Mechanical Power: 13.3 Hp Displacement: 479 cc Engine RPM: 3600 rpm Sound Pressure: 56 dB(A) @ 7 m ...

Maximum power Single-phase: 8.6 KW Single-phase continuous use power: 7.8 KW Fuel: Diesel Voltage: 230 V Frequency: 50 Hz Engine: Kubota D722 Length: 730 mm Width: 468 mm Height: 555 mm Weight: 185 Kg

Phase Type: Single Phase Maximum Power: 9.6 KVA / 9.6 KW Continuous Power: 8.8 KVA / 8. 8 KW Cos φ Factor: 1 Fuel: Diesel Voltage: 120 - 240 V Frequency: 60 Hz Engine: Kubota D722, 4 Stroke Emission Standard: EPA Tier III Mechanical Power: 20 Hp Displacement: 719 cc Engine RPM: 3600 rpm Sound Pressure: 56 dB(A) @ 7 m<br...

Phase Type: Single Phase Maximum Power: 8 KVA / 8 KW Factor cos φ: 1 Fuel: Diesel Voltage: 230 - 240 V Frequency: 50 - 60 Hz Motor: Kubota Z602, 4 Stroke Mechanical Power: 14. 5 Hp Displacement: 599 cc Engine speed: 2100 ÷ 3150 rpm Sound pressure: 54 dB(A) @ 7 m Alternator: Permanent Magnets (PMG) Consumption: 2.8 l/h @ 75 %<br...

Yanmar L100N engine Maximum power 6 kW Continuous power 4.8 kW Type: Diesel, 4-stroke, 1 cylinder Power: 8.8 hp (6.5 kWm) Bore/Stroke: 67.0 x 68.0 mm (2.64 x 2.68 inches) Displacement: 435 cm3 Injection system: Indirect injection Combustion: Naturally aspirated Fuel system: In-line pump Consumption at 100% load: 1.65 l/h Starter...
