Data sheet

Phase

Single phase

Maximum power single phase (KW)

7.4

Continuous power single phase (KW)

6.7

Maximum power single phase (KVA)

7.4

Continuous power single phase (KVA)

6.7

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230

Engine

KUBOTA D1105-BG

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

1124

Number cylinders

3

Oil capacity (L)

4

Cooling

With exchanger

Alternator

Synchronous, single bearing, self-regulated, self-excited, brushless, with electronic voltage regulator

Poles

4

Bore x stroke (mm)

78 x 78

Compression ratio

22 : 1

Consumption (L/h)

1.5 at 50% of the load / 2.7 at 100% of the load

Acoustic pressure

54 dB(A) at 7 m

Length (mm)

910

Width (mm)

540

Height (mm)

675

Dry weight (Kg)

286

Inverter

No

AVR

No

Compound

No

Silenced

Yes

Super silenced

Yes
