MASE IS 20 T MARINE GENERATOR THREE-PHASE 19.1KVA

Name: MASE IS 20 T MARINE GENERATOR THREE-PHASE 19.1KVA
Brand: MASE
SKU: 002607
Price: 29158 EUR
Availability: InStock

Reference 002607

Phase Type: Three Phase
Continuous Use Power: 17.4KVA
Maximum Power: 19.1KVA
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV88, 4 Stroke
Mechanical Power: 24. 5 Hp
Number of cylinders: 4
Displacement: 2190 cc
RPM controller: Centrifugal, mechanical
Engine speed: 1500 rpm
Acoustic power: 50 dBA @ 7 m
Length: 1115 mm
Width: 585 mm
Height: 730 mm
Weight: 400 Kg

Prezzo

23,900.00 € tax excl.

29,158.00 € tax incl.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference 002607

Data sheet

Phase: Three phase
Maximum power three phase (KW): 15.3
Continuous power three phase (KW): 13.9
Maximum power three phase (KVA): 19.1
Continuous power three phase (KVA): 17.4
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Engine: Yanmar 3TNV88, 4 stroke
Engine rpm (rpm): 1500
Speed governor: Centrifugal, mechanical
Engine capacity (cm³): 2190
Number cylinders: 4
Oil capacity (L): 7.4
Cooling: Air / water (Intercooler W/A)
Inyección: Direct
Alternator: Synchronous, self-excited
Poles: 4
Compression ratio: 19.1 : 1
Lubrication: Forced
Consumption (L/h): 5.6 at 100% of the load
Acoustic pressure: 50 dB(A) at 7 m
Length (mm): 1115
Width (mm): 585
Height (mm): 730
Dry weight (Kg): 400
Inverter: No
AVR: Yes
Compound: No
Silenced: Yes
Super silenced: Yes
Product type: Generator
Voltage regulator: AVR
Engine manufacturer: Yanmar

Specific References

Condition New

MASE IS 20 T THREE PHASE MARINE GENERATOR 19.1KVA

MASE IS20T marine generator three-phase with Yanmar 4TNV88 engine with diesel power supply at 1500 rpm capable of delivering a power of 19.1KVA.

The MASE IS20T marine generator is designed with a soundproof cabin that makes it supersilenced. The MASE IS20T is built with a Yanmar diesel-powered engine and synchronous alternator, self-excited with air/water cooling. With its small size, it is also suitable on small boats.

The marine generator CBU control module has a new design, the latest technology, a large display and micro-buttons for quick navigation of menus, start and stop procedures; IP54 protection rating. Very compact, 86x124mm and equipped with 10mts shielded cable, the CBU module has multiple functions for complete monitoring of the MASE IS20T.

The soundproof cabin of the MASE IS20T consists of a supporting structure in aluminum profile that supports panels in marine aluminum painted type 5754 extremely light and very high resistance to external agents. The excellent accessibility to the internal compartment makes maintenance operations easier, even when the genset is installed in narrow spaces.

Technical Features:
Phase Type: Three Phase
Continuous Use Power: 17.4KVA
Maximum Power: 19. 1KVA
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV88, 4 Stroke
Length: 1115 mm
Width: 585 mm
Height: 730 mm
Weight: 400 Kg

If you are looking for another generator as the MASE IS20T then you can see the entire catalog of marine generators .

Images and technical data are not binding.
