MASE IS 11.6 T MARINE GENERATOR THREE-PHASE 10KVA EPA

Reference MASE IS 11.6 T

Phase Type: Three Phase
Maximum Power: 11.5KVA
Fuel: Diesel
Voltage: 240 - 480 V
Frequency: 60 Hz
Engine: Yanmar 3TNV80F, 4 Stroke
Mechanical Power: 14. 35 Hp
Number of cylinders: 3
Displacement: 1267 cc
RPM controller: Centrifugal, mechanical
Engine speed: 1800 rpm
Acoustic power: 51 dBA @ 7 m
Length: 837 mm
Width: 568 mm
Height: 688 mm
Weight: 295 Kg

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MASE IS 11.6 T

Data sheet

Phase: Three phase
Maximum power three phase (KVA): 11.5
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 240 - 480 V
Engine: Yanmar 3TNV80F
Engine rpm (rpm): 1800
Speed governor: Centrifugal, mechanical
Engine capacity (cm³): 1267
Number cylinders: 3
Cooling: Air / water (Intercooler W/A)
Inyección: Direct
Alternator: Synchronous, self-excited
Poles: 4
Lubrication: Forced
Consumption (L/h): 3.1 at 100% of the load
Acoustic pressure: 51 dB(A) at 7 m
Length (mm): 837
Width (mm): 568
Height (mm): 688
Dry weight (Kg): 295
Inverter: No
AVR: Yes
Compound: No
Silenced: Yes
Super silenced: Yes
Product type: Generator
Voltage regulator: AVR
Engine manufacturer: Yanmar

Specific References

MASE IS 11.6 T THREE-PHASE MARINE GENERATOR 11.5KVA EPA

MASE IS11,6T three-phase marine generator with Yanmar 3TNV80F engine with diesel power supply at 1800 rpm capable of delivering a power of 11.5KVA.

The MASE IS11,6T marine generator is designed with a soundproof cabin that makes it supersilenced. The MASE IS11,6T marine generator is built with a diesel-powered Yanmar engine and synchronous, self-excited alternator with air/water cooling. With its small size, it is also suitable on small boats.

The marine generator CBU control module has a new design, the latest technology, a large display and micro-buttons for quick navigation of menus, start and stop procedures; IP54 protection rating. Very compact, 86x124mm and equipped with 10mts shielded cable, the CBU module has multiple functions for complete monitoring of the MASE IS11.6T.

The soundproof cabin of the MASE IS11,6T consists of a supporting structure in aluminum profile that supports panels in marine aluminum painted type 5754 extremely lightweight and high resistance to external agents. The excellent accessibility to the internal compartment makes maintenance operations easier even with the generator set installed in narrow spaces.

The MASE IS11.6T marine generator has EPA certification valid only for the U.S. market

Technical Features:
Phase Type: Three Phase
Maximum Power: 11.5KVA
Fuel: Diesel
Voltage: 240 - 480 V
Frequency: 60 Hz
Engine: Yanmar 3TNV80F, 4 Stroke
Length: 837 mm
Width: 568 mm
Height: 688 mm
Weight: 295 Kg

If you are looking for another generator as the MASE IS11,6T then you can see the entire catalog of marine generators .

Images and technical data are not binding.

Pellentesque habitant morbi tristique senectus et netus et malesuada fames ac turpis egestas. Aenean MASE IS11,6T scelerisque, elit quis mattis ultricies, ligula libero laoreet justo, non egestas est magna eget sem. Donec ut nulla at mauris pellentesque sollicitudin ut vitae velit. Aliquam massa enim, sagittis in ligula at, volutpat rutrum mauris. In non felis a magna rhoncus vulputate. Nunc varius in libero a MASE IS11,6T

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
