TECNOGEN LW16000TSS/A GENERATOR WITH SEPARATE AUTOMATIC PANEL
LW16000TSS/A - C
Maximum three-phase power: 14 KW
Maximum three-phase power: 17.5 KVA
Fuel: Diesel
Voltage: 400V
Engine: Lombardini LDW1003FOCS
Starting: Automatic
Length: 1750 mm
Width: 770 mm
Height: 1070 mm
Weight: 405 Kg
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 4.7
- Maximum power single phase (KVA)
- 5.8
- Maximum power three phase (KW)
- 14
- Maximum power three phase (KVA)
- 17.5
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Engine
- HONDA GC160
- Engine rpm (rpm)
- 3000
- Starting system
- Electric
- Engine capacity (cm³)
- 1028
- Number cylinders
- 3
- Cooling
- Water
- Fuel tank capacity (L)
- 54
- Consumption (L/h)
- 3.5
- Running time (h)
- 15.4
- Acoustic power
- 94 dB(A)
- Length (mm)
- 1750
- Width (mm)
- 770
- Height (mm)
- 1070
- Dry weight (Kg)
- 405
- Silenced
- No
- Super silenced
- Yes
- ATS Switch device
- ATS Included
- Voltage regulator
- Compound / AVR (optional)
- Engine manufacturer
- Lombardini
- Brand
-
TECNOGEN LW16000TSS/A GENERATOR WITH SEPARATE AUTOMATIC PANEL
Electric start diesel generators, water-cooled, 3000 rpm, available in both single-phase and three-phase versions, with powers from 11.7 to 34.7 kVA MAX. Sturdy and reliable, they are suitable to operate for long periods despite the high rotation rate. The set-up relative to the base-mounted versions includes a built-in fuel tank with a capacity of 52 l, a metal grille placed to protect the radiator and a professional electrical panel, entirely made of ABS with a high degree of protection, equipped with instruments that respect the strictest safety standards. The silenced models are also equipped with a soundproofed canopy in hot-dip galvanized steel. The generators of the W 3000 series are the ideal choice for applications with automatic intervention panel or for use in the mechanical / industrial field.
The image is purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
