GENSET MG 23 I-SY - SINGLE-PHASE/THREE-PHASE GENERATOR 20 KVA
MG 23 I-SY
Maximum power Three-phase: 20 KVA
Maximum power Three-phase: 16 KW
Power continuous use Three-phase: 18 KVA
Power continuous use Three-phase: 14.4 KW
Maximum power Single-phase: 5.6 KVA
Maximum power Single-phase: 4.48 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 3TNV88 (STAGE V)
Starting: Electric
Consumption: 3.5 Lt/h
Length: 1650 mm
Width: 700 mm
Height: 980 mm
Weight: 475 Kg
Super silenced
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 4.48
- Maximum power single phase (KVA)
- 5.6
- Maximum power three phase (KW)
- 16
- Continuous power three phase (KW)
- 14.4
- Maximum power three phase (KVA)
- 20
- Continuous power three phase (KVA)
- 18
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 32A CEE - 1 x 230V 32A CEE
- Engine
- Yanmar 4TNV88, 4 stroke
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 2190
- Number cylinders
- 4
- Cooling
- Water
- Alternator
- Synchronous
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 40
- Consumption (L/h)
- 3.5
- Running time (h)
- 11.43
- Acoustic power
- 91 dB(A)
- Acoustic pressure
- 66 dB(A) at 7 m
- Length (mm)
- 1650
- Width (mm)
- 700
- Height (mm)
- 980
- Dry weight (Kg)
- 475
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR (optional)
- Engine manufacturer
- Yanmar
- Brand
-
GENSET MG 23 I-SY
The GENSET MG 23 I-SY is a single-phase/three-phase 20 KVA diesel generator with electric start.
Thanks to its compact size and its very low weight, the GENSET MG 23 I-SY is a light and easy to transport generator.
The GENSET MG 23 I-SY also has a low fuel consumption: only 3.5 Lt/h at 75% of the load.
The GENSET MG 23 I-SY generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
