CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA

CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
search
  • CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
  • CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
  • CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
CGM
CGM 130DZ COFANATO AUTOMATICO
New product
Technical features
Phase
Three phase
Maximum power three phase (KW)
115
Continuous power three phase (KW)
104
Maximum power three phase (KVA)
143
Continuous power three phase (KVA)
130
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine
Deutz BF4M1013FC, turbo
Engine rpm (rpm)
1500
Speed governor
Mechanical
Starting system
Electric
Engine capacity (cm³)
4764
Number cylinders
4
Cylinders' position
In line
Cooling
Water
Alternator
Marelli, brushless
Poles
4
Protection degree
IP44
Bore x stroke (mm)
108 x 130
Fuel tank capacity (L)
250
Consumption (L/h)
20.3
Running time (h)
12.3
Acoustic pressure
69 dB(A) at 7 m
Length (mm)
3200
Width (mm)
1150
Height (mm)
2050
Dry weight (Kg)
1700
Silenced
Yes
Super silenced
Yes
ATS Switch device
Optional
Voltage regulator
AVR
Engine manufacturer
Deutz
Details
Technical Sheet / Manuals
icona_scheda

Technical data sheet CGM 130DZ

(1.08M)
Related Accessories
List price
49.849,20 € tax incl.
40.860,00 € tax excl.
Discounted Price
31.156,36 € tax incl.
25.538,00 € tax excl.
Quantity

loader
505,00 € shipped to Italy

Calculate Shipping Cost
Add to wishlist
Download PDF
Ask a question
Product: CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
Offer on letterhead
Product: CGM 100DZ - APERTO CON CENTRALINA AUTOMATICA
Technical features
Phase
Three phase
Maximum power three phase (KW)
115
Continuous power three phase (KW)
104
Maximum power three phase (KVA)
143
Continuous power three phase (KVA)
130
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine
Deutz BF4M1013FC, turbo
Engine rpm (rpm)
1500
Speed governor
Mechanical
Starting system
Electric
Engine capacity (cm³)
4764
Number cylinders
4
Cylinders' position
In line
Cooling
Water
Alternator
Marelli, brushless
Poles
4
Protection degree
IP44
Bore x stroke (mm)
108 x 130
Fuel tank capacity (L)
250
Consumption (L/h)
20.3
Running time (h)
12.3
Acoustic pressure
69 dB(A) at 7 m
Length (mm)
3200
Width (mm)
1150
Height (mm)
2050
Dry weight (Kg)
1700
Silenced
Yes
Super silenced
Yes
ATS Switch device
Optional
Voltage regulator
AVR
Engine manufacturer
Deutz
Details
Technical Sheet / Manuals
icona_scheda

Technical data sheet CGM 130DZ

(1.08M)
Related Accessories

Related Products
