Data sheet

Phase

Three phase

Maximum power three phase (KW)

115

Continuous power three phase (KW)

104

Maximum power three phase (KVA)

143

Continuous power three phase (KVA)

130

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

Deutz BF4M1013FC, turbo

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

4764

Number cylinders

4

Cylinders' position

In line

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Protection degree

IP44

Bore x stroke (mm)

108 x 130

Fuel tank capacity (L)

250

Consumption (L/h)

20.3

Running time (h)

12.3

Length (mm)

2400

Width (mm)

1100

Height (mm)

2000

Dry weight (Kg)

1200

Silenced

No

Super silenced

No

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

Deutz
