Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

11

Continuous power three phase (KW)

10

Maximum power three phase (KVA)

13.8

Continuous power three phase (KVA)

12.5

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 32A 5P CEE - 1 x 230V 16A 3P CEE

Engine

KOHLER 25LD 330/2

Engine rpm (rpm)

3000

Starting system

Electric

Engine capacity (cm³)

851

Number cylinders

2

Oil capacity (L)

1.7

Cooling

Air

Alternator

With brushes

Poles

2

Protection degree

IP55

Fuel tank capacity (L)

4

Consumption (L/h)

2.8 at 75% of the load

Running time (h)

1.4

Acoustic pressure

77 dB(A) at 7 m

Length (mm)

900

Width (mm)

600

Height (mm)

750

Dry weight (Kg)

170

Silenced

No

Super silenced

No

ATS Switch device

No

Voltage regulator

Compound

Engine manufacturer

Kohler
