Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

8.8

Continuous power three phase (KW)

8

Maximum power three phase (KVA)

11

Continuous power three phase (KVA)

10

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 CEE 5P 400V 16A + 1 CEE 3P 230V 16A

Engine

Lombardini LDW702

Engine rpm (rpm)

3000

Starting system

Electric

Engine capacity (cm³)

686

Number cylinders

2

Cylinders' position

In line

Cooling

Water

Alternator

With brushes

Poles

2

Protection degree

IP44

Bore x stroke (mm)

75 x 77.6

Fuel tank capacity (L)

50

Consumption (L/h)

2.9 at 75% of the load

Running time (h)

17.2

Length (mm)

1400

Width (mm)

700

Height (mm)

850

Dry weight (Kg)

240

Silenced

No

Super silenced

No

ATS Switch device

No

Voltage regulator

Compound

Engine manufacturer

Lombardini
