Data sheet

Phase

Three phase

Maximum power three phase (KW)

900

Continuous power three phase (KW)

818

Maximum power three phase (KVA)

1125

Continuous power three phase (KVA)

1022

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

PERKINS 4008 TAG2A

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

30561

Number cylinders

8

Cylinders' position

In line

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Protection degree

IP44

Bore x stroke (mm)

108 x 130

Fuel tank capacity (L)

400

Consumption (L/h)

163

Running time (h)

2.5 at 75% of the load

Length (mm)

4800

Width (mm)

2100

Height (mm)

2400

Dry weight (Kg)

7790

Silenced

No

Super silenced

No

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

Perkins
