Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

80

Continuous power three phase (KW)

72

Maximum power three phase (KVA)

100

Continuous power three phase (KVA)

90

Fuel

LPG

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

General Motors RMG 8000

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

7900

Number cylinders

8

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Bore x stroke (mm)

107.95 x 107.95

Consumption (L/h)

41 at 100% of the load

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

2600

Width (mm)

1100

Height (mm)

2000

Dry weight (Kg)

1550

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

General Motors
