Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

26.4

Continuous power three phase (KW)

24

Maximum power three phase (KVA)

33

Continuous power three phase (KVA)

30

Fuel

LPG

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 63A 5P - 1 x 230V 16A 3P

Engine

General Motors RMG 3000

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

3000

Number cylinders

4

Cylinders' position

In line

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Bore x stroke (mm)

101.6 x 91.4

Consumption (L/h)

15.1 at 100% of the load

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

2200

Width (mm)

1000

Height (mm)

1500

Dry weight (Kg)

920

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

General Motors
