Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

44

Continuous power three phase (KW)

40

Maximum power three phase (KVA)

55

Continuous power three phase (KVA)

50

Fuel

Natural Gas

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

General Motors RMG 5700

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

5700

Number cylinders

8

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Bore x stroke (mm)

101.6 x 91.4

Natural Gas consumption (m³/h)

18.1 at 100% of the load

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

2200

Width (mm)

1000

Height (mm)

1800

Dry weight (Kg)

1300

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

General Motors
