PRAMAC GSL65D

Reference SG610TDAU00 /

OUT OF PRODUCTION

Maximum power Three-phase: 51.47 KW
Three-phase continuous use power: 48.76 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Deutz BF4M2011C Stage II
Starting: Electric
Consumption: 14.7 Lt/h at 100% of the load
Length: 2200 mm
Width: 1000 mm
Height: 1620 mm
Weight: 954 Kg
AVR

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference SG610TDAU00 /

Data sheet

Phase: Three phase
Maximum power three phase (KW): 51.47
Continuous power three phase (KW): 48.76
Maximum power three phase (KVA): 64.34
Continuous power three phase (KVA): 60.95
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Emissions Regulations: Stationary Use
Speed governor: Mechanical
Starting system: Electric
Engine capacity (cm³): 5650
Number cylinders: 6
Cylinders' position: In line
Oil capacity (L): 13.5
Cooling: Air
Alternator: Mecc Alte ECO/P32-2L/4, brushless
Poles: 4
Fuel tank capacity (L): 240
Consumption (L/h): 10.7 at 75% of the load / 14.7 at 100% of the load
Running time (h): 22.4 at 75% of the load / 16.3 at 100% of the load
Length (mm): 2200
Width (mm): 1000
Height (mm): 1620
Dry weight (Kg): 954
Inverter: No
AVR: Yes
Compound: No
Silenced: No
Super silenced: No

Specific References

Condition New

Compliance with Directive 2000/14/EC on environmental noise emissions and the high level of safety, which minimizes the danger of unauthorized use or accidental damage, make this series of generators suitable for all industrial and residential applications.

DEUTZ diesel engines (prepared for BIODIESEL)
● Oil cooling with radiator
● MECCALTE electronic control alternators
● Galvanized casing with residential muffler
● Lifting hook and forklift base with trolleys
● Motor fluids and charged battery
● Oil extraction piping
● MCP cabinet with 4 service sockets (GSL65 optional)
● ETB terminal block power connection GSL65
● KPR Dispersed liquid collection basin (std ACP)

The images are purely indicative.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
