Data sheet

Phase

Three phase

Maximum power three phase (KW)

25.55

Continuous power three phase (KW)

24.31

Maximum power three phase (KVA)

31.94

Continuous power three phase (KVA)

30.39

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

Deutz AG F4L2011, naturally aspirated

Emissions Regulations

Stationary Use

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3110

Number cylinders

4

Cylinders' position

In line

Oil capacity (L)

10

Cooling

Air

Alternator

Mecc Alte ECP28-VL/4, brushless

Poles

4

Fuel tank capacity (L)

91

Consumption (L/h)

5.7 at 75% of the load / 7.5 at 100% of the load

Running time (h)

15.9 at 75% of the load / 12.1 at 100% of the load

Length (mm)

1400

Width (mm)

750

Height (mm)

1700

Dry weight (Kg)

663

Inverter

No

AVR

Yes

Compound

No

Silenced

No

Super silenced

No

Product type

Generator

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

Deutz
