MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

Name: MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV
Brand: MASE
SKU: 002309MA
Price: 3300 EUR
Availability: InStock

Type of phase: Single-phase
Continuous power: 3.5 KVA / 2.8 KW
Maximum power: 4.3 KVA / 3.4 KW
VAC voltage: 230 V
Frequency (Hz ): 50
Voltage regulator: Capacitor (AVR Optional)
Ignition panel: Electric
Engine: Yanmar L70V
Emissions standard: Stage V
Revolutions per minute: 3000 rpm
Power supply: Diesel
Socket panel: 2 x CEE 16A 230V
Tank capacity: 3.5 l
Autonomy: 3.5 h at 75% of load
Consumption: 1 l / h at 75% load
Acoustic pressure: 74 dB (A) @ 7 m
Length: 725 mm
Width: 515 mm
Height: 585 mm
Net weight: 87 Kg

List price

4,026.00 € tax incl.

3,300.00 € tax excl.

Discounted Price

4,026.00 € tax incl.

3,300.00 € tax excl.

Shipping Free to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Product: MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

Start of Rental

End of Rental

Where to collect / receive the Product

Do you need cables?

SÌNO

Additional Tank?

SÌNO

PERSONAL DATA

Name

Surname

Phone

Company

City

State

Postal Code

Country

VAT or CF

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Ask a question

Product: MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

Full Name

Company

Phone

City

Country

Postal code

Message

reCAPTCHA

Offer on letterhead

Product: MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

Name

Surname

Company

VAT

Phone

City

Country

Postal code

Shipping address

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference 002309MA

Data sheet

Phase: Single phase
Maximum power single phase (KW): 3.4
Continuous power single phase (KW): 2.8
Maximum power single phase (KVA): 4.3
Continuous power single phase (KVA): 3.5
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230
Sockets configuration: 2 x 230V 16A 2P+T CEE
Engine: Yanmar L70AE, 4 stroke
Emissions Regulations: Stage 5
Engine rpm (rpm): 3000
Starting system: Electric
Engine capacity (cm³): 320
Number cylinders: 1
Cooling: Air
Alternator: Synchronous
Fuel tank capacity (L): 3.5
Consumption (L/h): 1 at 75% of the load
Running time (h): 3.5 at 75% of the load / 2.6 at 100% of the load
Acoustic power: 99 dB(A)
Acoustic pressure: 74 dB(A) at 7 m
Length (mm): 725
Width (mm): 515
Height (mm): 585
Dry weight (Kg): 87
Silenced: No
Super silenced: No
ATS Switch device: Optional
Voltage regulator: Capacitor / AVR (optional)
Engine manufacturer: Yanmar

Specific References

Condition New

MASE PD 40 Y GENERATOR 4,3KVA SINGLE PHASE STAGEV

MASE PD 40 Y is a single-phase generator equipped with a diesel-supplied Yanmar L70V StageV engine, deliver a maximum power of 4,3KVA, complete with capacitor voltage regulator ( AVR optional ).

The generator is equipped with an electric start and has a low fuel consumption, in fact it consumes only 1 liters / hour at 75% of the load for an autonomy of up to 3.5 hours of operation.

MASE PD 40 Y provides reliable power for home, business and leisure environments Safely powering home appliances and other electronic devices Power solution for outdoor parties. Extremely practical sockets and controls make starting and operating easier, making these operations extremely simple and fast.

MASE PD 40 Y is equipped with a completely steel structure and a tank with a maximum capacity of 3.5 liters. The MASE PD 40 Y guarantees efficient and silent operation thanks to the Yanmar L70V StageV engine .

STAGEV EMISSIONS REGULATION

With the abbreviation STAGEV, the guidelines and the limits of the gas emissions of the engines are defined. The legislation is respected through the installation of special anti-particulate filters, but an indispensable condition for the filter to work properly is that the generating set works at its design temperature.

TECHNICAL CHARACTERISTICS OF MASE PD 40 Y

Type of phase: Single-phase
Continuous power: 3.5 KVA / 2.8 KW
Maximum power: 4.3 KVA / 3.4 KW
VAC voltage: 230 V
Frequency (Hz ): 50
Voltage regulator: Capacitor (AVR Optional)
Ignition panel: Electric
Engine: Yanmar L70V
Emissions standard: Stage V
Revolutions per minute: 3000 rpm
Fuel: Diesel
Socket panel: 2 x CEE 16A 230V
Tank capacity: 3.5 l
Autonomy: 3.5 h at 75% of load
Consumption: 1 l / h at 75% load
Acoustic pressure: 74 dB (A) @ 7 m
Length: 725 mm
Width: 515 mm
Height: 585 mm
Net weight: 87 Kg

Are you looking for a product with different technical characteristics? HERE you can find the area dedicated to MASE generators and other specialized brands.

Non-binding images and technical data.
