Data sheet

Phase

Single phase / Three phase

Maximum power single phase (KW)

13.3

Continuous power single phase (KW)

18

Maximum power single phase (KVA)

16

Continuous power single phase (KVA)

22.5

Maximum power three phase (KW)

40

Continuous power three phase (KW)

36

Maximum power three phase (KVA)

50

Continuous power three phase (KVA)

45

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

PERKINS 1103A-33TG1, aspirazione sovralimentata

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3300

Number cylinders

3

Cooling

Water

Alternator

Leroy Somer LSA43.2 S25, brushless

Poles

4

Bore x stroke (mm)

105 x 127

Fuel tank capacity (L)

135

Consumption (L/h)

9 at 100% of the load

Running time (h)

15 at 100% of the load

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

1940

Width (mm)

1000

Height (mm)

1480

Dry weight (Kg)

1200

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
