Data sheet

Phase

Single phase / Three phase

Maximum power single phase (KW)

8.8

Continuous power single phase (KW)

7.9

Maximum power single phase (KVA)

11

Continuous power single phase (KVA)

9.9

Maximum power three phase (KW)

26.4

Continuous power three phase (KW)

24

Maximum power three phase (KVA)

33

Continuous power three phase (KVA)

30

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

John Deere 3029 DF 128, naturally aspirated

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

2900

Number cylinders

3

Cooling

Water

Alternator

Mecc Alte ECO 28 VL4, brushless

Poles

4

Bore x stroke (mm)

106 x 110

Fuel tank capacity (L)

135

Consumption (L/h)

7 at 100% of the load

Running time (h)

19.28 at 100% of the load

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

1940

Width (mm)

1000

Height (mm)

1480

Dry weight (Kg)

960

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

John Deere
