Data sheet

Phase

Single phase / Three phase

Maximum power single phase (KW)

5.8

Maximum power single phase (KVA)

7.3

Maximum power three phase (KW)

17.6

Maximum power three phase (KVA)

22

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 16A 5P CEE - 1 x 230V 16A 3P CEE

Engine

Lombardini LDW2204

Engine rpm (rpm)

1500

Starting system

Electric

Engine capacity (cm³)

2199

Number cylinders

4

Oil capacity (L)

4.5

Cooling

Coolant Liquid

Fuel tank capacity (L)

46

Consumption (L/h)

6 at 100% of the load

Running time (h)

7.66 at 100% of the load

Acoustic power

94 dB(A)

Acoustic pressure

69 dB(A) at 7 m

Length (mm)

1480

Width (mm)

680

Height (mm)

1140

Dry weight (Kg)

540

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

No

Engine manufacturer

Lombardini
