Data sheet

Phase

Single phase

Maximum power single phase (KW)

6.4

Continuous power single phase (KW)

5.5

Maximum power single phase (KVA)

7.2

Continuous power single phase (KVA)

6

Fuel

Gasoline

Frequency (Hz)

50

Voltage (V)

230

Sockets configuration

Engine

Honda GX390 Electric, naturally aspirated

Engine rpm (rpm)

3000

Speed governor

Mechanical

Starting system

Elettrico

Engine capacity (cm³)

389

Oil capacity (L)

1.1

Cooling

Air

Poles

2

Fuel tank capacity (L)

26.5

Consumption (L/h)

2.14 at 75% of the load / 2.87 at 100% of the load

Running time (h)

12.38 at 75% of the load / 9.23 at 100% of the load

Acoustic power

97 dB(A)

Acoustic pressure

73 dB(A) at 7 m

Length (mm)

840

Width (mm)

615

Height (mm)

753

Dry weight (Kg)

109

Silenced

No

Super silenced

No

Product type

Generator

ATS Switch device

Optional

Voltage regulator

Capacitor

Engine manufacturer

Honda
