Data sheet

Phase

Three phase

Maximum power three phase (KW)

53.54

Continuous power three phase (KW)

48.58

Maximum power three phase (KVA)

66.93

Continuous power three phase (KVA)

60.73

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

PERKINS 1103A-33TG2, turbocharged

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3300

Number cylinders

3

Cylinders' position

In line

Oil capacity (L)

8.3

Cooling

Water

Alternator

Mecc Alte ECO/P32-2L/4, brushless

Poles

4

Fuel tank capacity (L)

209

Consumption (L/h)

10.4 at 75% of the load / 13.9 at 100% of the load

Running time (h)

20.1 at 75% of the load / 15 at 100% of the load

Acoustic power

96 dB(A)

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

2285

Width (mm)

920

Height (mm)

1465

Dry weight (Kg)

1085

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
