Data sheet

Phase

Three phase

Maximum power three phase (KW)

53.14

Continuous power three phase (KW)

48.18

Maximum power three phase (KVA)

66.43

Continuous power three phase (KVA)

60.22

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

FPT NEF45SM1A, turbo intercooled

Emissions Regulations

Stage 2

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

4500

Number cylinders

4

Cylinders' position

In line

Oil capacity (L)

12.8

Cooling

Water

Alternator

Mecc Alte ECO/P32-2L/4, brushless

Poles

4

Fuel tank capacity (L)

209

Consumption (L/h)

10.2 at 75% of the load / 13.7 at 100% of the load

Running time (h)

20.4 at 75% of the load / 15.3 at 100% of the load

Acoustic power

95 dB(A)

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

2400

Width (mm)

1000

Height (mm)

1530

Dry weight (Kg)

1440

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

FPT Iveco
