Data sheet

Phase

Three phase

Maximum power three phase (KW)

505.45

Continuous power three phase (KW)

458.3

Maximum power three phase (KVA)

631.81

Continuous power three phase (KVA)

572.87

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

Doosan DP180LA, turbo intercooled

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

18273

Cooling

Water

Alternator

Mecc Alte ECO40-1.5L/4, brushless

Poles

4

Fuel tank capacity (L)

636

Consumption (L/h)

95.8 at 75% of the load / 129.8 at 100% of the load

Running time (h)

6.6 at 75% of the load / 4.9 at 100% of the load

Length (mm)

3500

Width (mm)

1500

Height (mm)

2100

Dry weight (Kg)

3900

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Doosan
