PRAMAC GSW50Y COFANATO CON QUADRO COMANDO MANUALE

PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
search
  • PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
  • PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
PRAMAC
SU440TYAX00 /
New product

OUT OF PRODUCTION

Technical features
Phase
Three phase
Maximum power three phase (KW)
37.03
Continuous power three phase (KW)
35.18
Maximum power three phase (KVA)
46.29
Continuous power three phase (KVA)
43.97
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Sockets configuration
1 x 400V 63A 3P+N+T - 1 x 400V 32A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
Engine
Yanmar 4TNV98T-ZGPGE, turbocharged
Emissions Regulations
Stage 3A
Speed governor
Electronic
Starting system
Electric
Engine capacity (cm³)
3319
Number cylinders
4
Cylinders' position
In line
Oil capacity (L)
11.2
Cooling
Water
Alternator
Mecc Alte ECO/P32-3S/4, brushless
Poles
4
Fuel tank capacity (L)
68
Consumption (L/h)
8.3 at 75% of the load / 11.1 at 100% of the load
Running time (h)
8.2 at 75% of the load / 6.1 at 100% of the load
Acoustic power
95 dB(A)
Acoustic pressure
66 dB(A) at 7 m
Length (mm)
2000
Width (mm)
920
Height (mm)
1310
Dry weight (Kg)
839
Silenced
Yes
Super silenced
Yes
Product type
Generator
ATS Switch device
No
Voltage regulator
AVR
Engine manufacturer
Yanmar
Details
* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
Technical Sheet / Manuals

Scheda tecnica GSW50Y COFANATO

(944.52k)

Technical data GSW50Y COVERED

(944.18k)

Disegno installazione GSW50Y

(415.36k)

Disegno installazione GSW50Y EFT

(428.28k)
