Data sheet

Phase

Three phase

Maximum power three phase (KW)

220

Continuous power three phase (KW)

201.18

Maximum power three phase (KVA)

275

Continuous power three phase (KVA)

251.48

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

VOLVO TAD734GE, turbo intercooled

Emissions Regulations

Stage 2

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

7150

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

29

Cooling

Water

Alternator

Mecc Alte ECO38-1LN/4, brushless

Poles

4

Fuel tank capacity (L)

400

Consumption (L/h)

44.6 at 75% of the load / 55.1 at 100% of the load

Running time (h)

9 at 75% of the loado / 7.3 at 100% of the load

Length (mm)

2672

Width (mm)

1181

Height (mm)

1844

Dry weight (Kg)

2177

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Volvo
