PRAMAC GSW22P COFANATO CON QUADRO COMANDO MANUALE

PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
search
  • PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
  • PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)
PRAMAC
SU200TPAR00
New product
Technical features
Phase
Three phase
Maximum power three phase (KW)
17.2
Continuous power three phase (KW)
16.08
Maximum power three phase (KVA)
21.5
Continuous power three phase (KVA)
20.1
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Sockets configuration
1 x 400V 32A 3P+N+T - 1 x 400V 16A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
Engine
PERKINS 404D-22G, naturally aspirated
Emissions Regulations
Stage 3A
Speed governor
Mechanical
Starting system
Electric
Engine capacity (cm³)
2216
Number cylinders
4
Cylinders' position
In line
Oil capacity (L)
10.6
Cooling
Water
Alternator
Mecc Alte ECP28-M/4, brushless
Poles
4
Fuel tank capacity (L)
68
Consumption (L/h)
4 at 75% of the load / 5.3 at 100% of the load
Running time (h)
17.1 at 75% of the load / 12.9 at 100% of the load
Acoustic power
87 dB(A)
Acoustic pressure
58 dB(A) at 7 m
Length (mm)
1800
Width (mm)
850
Height (mm)
1260
Dry weight (Kg)
730
Silenced
Yes
Super silenced
Yes
Product type
Generator
ATS Switch device
No
Voltage regulator
AVR
Engine manufacturer
Perkins
Details
Technical Sheet / Manuals
icona_scheda

Scheda tecnica GSW22P COFANATO

(930.8k)
icona_scheda

Technical data GSW22P COVERED

(930.19k)
icona_scheda

Disegno installazione GSW22P

(404.67k)
icona_scheda

Disegno installazione GSW22P EFT

(419.4k)
Related Accessories
List price
19.825,00 € tax incl.
16.250,00 € tax excl.
Discounted Price
10.240,68 € tax incl.
8.394,00 € tax excl.
Quantity

loader
215,00 € shipped to Italy

Calculate Shipping Cost
Add to wishlist
Download PDF
Ask a question
