Data sheet

Phase

Three phase

Maximum power three phase (KW)

176

Continuous power three phase (KW)

162.14

Maximum power three phase (KVA)

220

Continuous power three phase (KVA)

202.67

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

VOLVO TAD733GE, turbo intercooled

Emissions Regulations

Stage 2

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

7150

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

34

Cooling

Water

Alternator

Mecc Alte ECO38-2SN/4, brushless

Poles

4

Fuel tank capacity (L)

400

Consumption (L/h)

34.9 at 75% of the load / 46.5 at 100% of the load

Running time (h)

11.5 at 75% of the load / 8.6 at 100% of the load

Length (mm)

2650

Width (mm)

1180

Height (mm)

1965

Dry weight (Kg)

2026

Silenced

No

Super silenced

No

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

Volvo
