HYUNDAI PT6500-T-ATS Generator Single-phase Petrol AVR 5.5Kw

Name: HYUNDAI PT6500-T-ATS Generator Single-phase Petrol AVR 5.5Kw
SKU: 65130
Price: 639 EUR
Availability: InStock

Brand: HYUNDAI

Reference: 65130

Equipped with ATS

Phase type: Single-phase

Maximum single-phase power: 5.5 kW

Continuous single-phase power: 5 kW

Fuel: Petrol

Frequency: 50 Hz

Voltage: 230 V

Socket configuration: 2 x 16A

Engine: PT190F

Starting system: Electric

Displacement: 420 cm³

Alternator: 140 mm with copper brushes

AVR: Yes

Oil capacity: 0.6 L

Sound pressure level: 96 dB(A) at 7 m at 50% load

Fuel tank capacity: 25 L

Control panel: Voltmeter

Length: 600 mm

Width: 457 mm

Height: 447 mm

Dry weight: 70 kg

Emissions standard: Stage 5

Technical features

Phase: Single phase
Maximum power single phase (KW): 5.5
Continuous power single phase (KW): 5
Fuel: Gasoline
Frequency (Hz): 50
Voltage (V): 230
Sockets configuration: 2X16A
Engine: PT190F
Emissions Regulations: Stage 5
Starting system: Elettrico
Engine capacity (cm³): 420
Oil capacity (L): 0.6
Alternator: 140 mm with COPPER brushes
Fuel tank capacity (L): 25
Acoustic pressure: 96 dB(A) at 7m at 50% load
Length (mm): 600
Width (mm): 457
Height (mm): 447
Dry weight (Kg): 70
AVR: Yes
Remote panel: Voltmeter

Details

HYUNDAI PT6500-T-ATS GENERATOR PETROL SINGLE-PHASE AVR 5.5KW

The HYUNDAI PT6500-T-ATS Generator Petrol Single-Phase AVR 5.5Kw is the ideal choice for those looking for power, reliability, and autonomy during emergencies or for daily outdoor use. Equipped with electric start and integrated ATS system, the HYUNDAI PT6500-T-ATS ensures automatic power supply in case of blackout, providing continuity and safety.

Thanks to its powerful 15 HP HYUNDAI PT190F petrol engine and 420 cc displacement, the HYUNDAI PT6500-T-ATS Petrol Single-Phase Generator AVR 5.5Kw delivers a maximum power of 5.5 kW and a rated power of 5.0 kW, perfect for powering lights, appliances, and work tools.

The AVR (Automatic Voltage Regulator) system protects connected devices from voltage fluctuations, while the 140 mm copper alternator with brushes ensures efficiency and long service life. The HYUNDAI PT6500-T-ATS Petrol Single-Phase Generator AVR 5.5Kw complies with EURO 5 regulations, minimizing harmful emissions and reducing environmental impact.

Other technical features of HYUNDAI PT6500-T-ATS Generator:

Voltage and frequency: 230V / 50Hz

Outlets: 2 x 16A + 1 x 12V socket

Fuel tank: 25 liters, for extended autonomy

Noise level: 96 dBa at 7 meters (50% load)

Net weight: 70 kg

Dimensions: 60 x 45.7 x 44.7 cm

Built-in voltmeter and included VRLA-AGM battery

The HYUNDAI PT6500-T-ATS Petrol Generator is designed to be robust, compact, and easy to use. The intuitive control panel combined with the convenience of the electric start makes this generator suitable even for non-expert users.

The HYUNDAI PT6500-T-ATS Petrol Single-Phase Generator AVR 5.5Kw is an essential device for those who need a reliable power source ready to use in any situation. Whether for a construction site, a home, or a commercial activity, this generator stands for quality, efficiency, and cutting-edge technology.

Looking for a generator like the HYUNDAI PT6500-T-ATS but with different features? CLICK HERE to explore our full range.

Images and technical data are not binding. Please always consult the technical data sheet issued by the manufacturer. Manel Service accepts no liability for any changes made by the manufacturer.
