Data sheet

Phase

Three phase

Maximum power three phase (KW)

131.2

Continuous power three phase (KW)

123.95

Maximum power three phase (KVA)

164

Continuous power three phase (KVA)

154.94

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

VOLVO TAD731GE, turbo intercooled

Emissions Regulations

Stage 2

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

7150

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

20

Cooling

Water

Alternator

Mecc Alte ECP34-2L, brushless

Poles

4

Fuel tank capacity (L)

350

Consumption (L/h)

26.8 at 75% of the load / 35.3 at 100% of the load

Running time (h)

13 at 75% of the load / 9.9 at 100% of the load

Acoustic power

97 dB(A)

Acoustic pressure

68 dB(A) at 7 m

Length (mm)

3400

Width (mm)

1250

Height (mm)

1770

Dry weight (Kg)

2224

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

AVR

Engine manufacturer

Volvo
