Data sheet

Phase

Three phase

Maximum power three phase (KW)

131.2

Continuous power three phase (KW)

126.4

Maximum power three phase (KVA)

164

Continuous power three phase (KVA)

158

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

FPT NEF67TM3A, turbo aftercooler

Emissions Regulations

Stage 2

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

6

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

17.2

Cooling

Water

Alternator

Mecc Alte ECP34-2L, brushless

Poles

4

Fuel tank capacity (L)

240

Consumption (L/h)

27.1 at 75% of the load / 35.6 at 100% of the load

Running time (h)

8.9 at 75% of the load / 6.7 at 100% of the load

Acoustic power

96 dB(A)

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

3400

Width (mm)

1250

Height (mm)

1770

Dry weight (Kg)

2057

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

FPT Iveco
