Data sheet

Phase

Three phase

Maximum power three phase (KW)

140.21

Continuous power three phase (KW)

101.97

Maximum power three phase (KVA)

140.21

Continuous power three phase (KVA)

127.46

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

FPT NEF67SM1A, turbocharged

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

6

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

17.2

Cooling

Water

Alternator

Mecc Alte ECP34-1L, brushless

Poles

4

Fuel tank capacity (L)

350

Consumption (L/h)

21.5 at 75% of the load / 28.2 at 100% of the load

Running time (h)

16.2 at 75% of the load / 12.4 at 100% of the load

Acoustic power

97 dB(A)

Acoustic pressure

68 dB(A) at 7 m

Length (mm)

3400

Width (mm)

1250

Height (mm)

1770

Dry weight (Kg)

1995

Inverter

No

AVR

Yes

Compound

No

Silenced

Yes

Super silenced

Yes
