Product sold with:
Liquid/diesel collection tank
General Differential Relay
Automatic battery chargers
Battery Cut-Off Switch
Oil extraction pump
Engine Oil Pressure Transmitter
Engine Coolant Temperature Transmitter
Analog Diesel level sensor / alarm in control unit
Digital sensor for the presence of liquids in the containment basin
Radiator water level sensor
Phase type: Single-phase / Three-phase
Maximum three-phase power (KW): 88
Continuous three-phase use power (KW): 80
Maximum three-phase power (KVA): 110
Continuous three-phase power (KVA): 100
Frequency (Hz): 50
Voltage (V): 230 / 400
Engine: FPT NEF45 TM2A
Engine speed (rpm): 1500
Displacement (cm³): 4500
Number of cylinders: 4
Cooling: Water
Consumption (L/h): 75% (l/h) 15.75
Sound pressure: 55 dB(A) at 7 m
Length (mm): 3000
Width (mm): 1500
Height (mm): 2000
Dry weight (Kg): 2800
Silent: Yes
Product Type: Generator
Engine Brand: FPT Iveco
Emissions Standard: Stage 2
Tank: 360 L
The NED 88KW Stage II Generating Set is an industrial electric generator designed to offer exceptional performance and maximum reliability, even in the most demanding conditions. With a continuous output of 88 kW and an FPT NEF45TM2A engine, this generator set is the ideal solution for a wide range of applications, providing emergency or continuous power supply.
Key Features:
Powerful and reliable: The 4-cylinder FPT NEF45TM2A engine, with a displacement of 4.5 liters, ensures high performance and a long service life.
Quiet: Thanks to the soundproofed construction with class A1 rock wool, the noise level is extremely low, ensuring discrete operation.
Versatile: Available in single-phase and three-phase configurations, with an output voltage of 230/400 V and a frequency of 50 Hz, it adapts to various application requirements.
Economical: Low consumption of 15.75 l/h at 75% load makes it a cost-effective solution.
Robust: The galvanized steel construction and high-quality components guarantee a long service life.
Environmentally friendly: Compliant with Stage II emission regulations and environmentally friendly.
Technical characteristics:
Phase Type: Single Phase / Three Phase
Maximum Power: 110 KVA / 88 KW
Continuous Power: 100 KVA / 80 KW
Voltage: 230/400 V
Frequency: 50 Hz
Engine: FPT NEF45TM2A}
Standard emissions: Stage II
Number of cylinders: 4
Displacement: 4.5 l
Engine revs: 1500
Acoustic power: 55 db (A) at 7m
FUEL CONSUMPTION 75% (l/h): 15.75
Cooling: water
Regulator: AVR
Length: 3000 mm
Width: 1500 mm
Height: 2000 mm
Net weight: 2800 kg
Tank: 360 L
Structure material: Galvanized steel
Soundproofing material: Rock wool with resistance class a1
Alternator: Stamford
Insulation Class: H
Degree of protection: IP23
number of poles: 4
Are you looking for a product with different technical characteristics?HERE you can find the area dedicated to WHISPER vehicle generators or those of other specialized brands.
Images and non-binding technical data.
