GENSET MGF16000Y Single-Phase Generator Group 14.5KVA

The GENSET MGF16000Y Single-Phase Generator Group 14.5 KVA is an ideal solution for those who need a
reliable and silent power source. Equipped with a Yanmar engine running at 1500 rpm, this
GENSET MGF16000Y is designed for automatic starting, ensuring simple and efficient operation in
any situation.

The openable casing of the GENSET MGF16000Y Single-Phase Generator Group 14.5 KVA allows for
easy and quick maintenance, while the lifting hook and forkliftable base enable practical and safe handling.
With a single-phase maximum power of 14.5 KVA and a maximum power of 11.6 KW, the
GENSET MGF16000Y Single-Phase Generator Group is perfect for a wide range of applications.

Technical Specifications of GENSET MGF16000Y:

Single-phase maximum power: 14.5 KVA
Maximum power: 11.6 KW
Fuel: Diesel
Voltage: 230 V
Acoustic power: 96 Lwa (71 dB at 7 meters)
Frequency: 50 Hz
Engine: Yanmar 3 TNV 88 (STAGE V)
RPM: 1500
Number of cylinders: 3
Displacement: 1642 cm³
Engine power: 18.1 HP (13.5 kWm)
Cooling: Liquid coolant
Starting system: Electric
Tank capacity: 40 liters
Fuel consumption @75%: 2.7 liters/hour
Protection rating: IP23
Dimensions (L x W x H): 1430 x 690 x 930 mm
Weight: 430 kg

The GENSET MGF16000Y Single-Phase Generator Group 14.5 KVA is designed to offer high and durable
performance. The Yanmar engine, known for its reliability, ensures efficient operation with reduced
fuel consumption, making it an economical and sustainable choice.

The GENSET MGF16000Y Single-Phase Generator Group 14.5 KVA is the perfect choice for applications
that require a combination of performance, efficiency, and durability.

Main Features GENSET MGF16000Y:

Quiet and efficient: with an acoustic power of 96 Lwa and only 71 dB at 7 meters, it is suitable for
environments where noise must be minimized.
Easy maintenance: the openable casing allows for quick access for maintenance interventions.
Simple handling: the lifting hook and forkliftable base facilitate transportation and installation.
Automatic starting: designed for automatic starting, enhancing reliability and ease of use.

The GENSET MGF16000Y Single-Phase Generator Group 14.5 KVA represents an excellent choice
for those seeking a powerful, quiet, and easy-to-maintain single-phase generator, with all the
necessary features for continuous and reliable operation.

Looking for a power generator with different characteristics? Here you can find the full range of products from GENSET or other brands specializing in the field

Images and technical data are not binding and may be subject to revision by the supplier.
