PRAMAC GSL42D

PRAMAC GSL42D
search
  • PRAMAC GSL42D
  • PRAMAC GSL42D
PRAMAC
PRAMAC GSL42D
New product

OUT OF PRODUCTION

Maximum power Three-phase: 35.62 KW
Power continuous use Three-phase: 33.85 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Deutz AG BF4M2011
Starting: Electric
Consumption: 11.2 Lt/h at 100% of the load
Length: 1800 mm
Width: 750 mm
Height: 1518 mm
Weight: 761 Kg
AVR

Technical features
Phase
Three phase
Maximum power three phase (KW)
35.62
Continuous power three phase (KW)
33.85
Maximum power three phase (KVA)
44.52
Continuous power three phase (KVA)
42.31
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Engine
Deutz AG BF4M2011, turbo
Speed governor
Mechanical
Starting system
Electric
Engine capacity (cm³)
3110
Number cylinders
4
Cylinders' position
In line
Oil capacity (L)
10
Cooling
Oil
Alternator
Mecc Alte ECO/P32-3S/4, brushless
Poles
4
Fuel tank capacity (L)
91
Consumption (L/h)
8.1 at 75% of the load / 11.2 at 100% of the load
Running time (h)
11.3 at 75% of the load / 8.1 at 100% of the load
Length (mm)
1800
Width (mm)
750
Height (mm)
1518
Dry weight (Kg)
761
Silenced
No
Super silenced
No
ATS Switch device
Optional
Voltage regulator
AVR
Engine manufacturer
Deutz
Details

Motore Diesel. Predisposto per Biodiesel. Raffreddamento ad olio con radiatore. Silenziatore industriale. Base forcabile con carrelli. Liquidi motore e batteria carica

Technical Sheet / Manuals

Scheda tecnica GSL42D APERTO

(530.85k)

Technical data GSL42D OPEN

(567.39k)

Disegno installazione GSL42D

(434.18k)
