GENSET MGF 44 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 44 KVA AVR STAGE V

Name: GENSET MGF 44 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 44 KVA AVR STAGE V
Brand: GENSET
SKU: MGF 44 Y - STAGE 5
Price: 21472 EUR
Availability: InStock

Reference MGF 44 Y - STAGE 5

Maximum power Three-phase: 44 KVA
Maximum power Three-phase: 35.2 KW
Maximum power Single-phase: 14.7 KVA
Maximum power Single-phase: 11.76 KW
Fuel: Diesel
Voltage: 400 V - 230 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98T (STAGE 5)
Starting: Electric
Consumption: 8.1 Lt/h
Length: 1640 mm
Width: 770 mm
Height: 1076 mm
Weight: 725 Kg
Super silenced
AVR

List price

38,308.00 € tax incl.

31,400.00 € tax excl.

Discounted Price

21,472.00 € tax incl.

17,600.00 € tax excl.

Shipping from 262.30 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MGF 44 Y - STAGE 5

Data sheet

Phase: Three phase
Maximum power single phase (KW): 11.76
Maximum power single phase (KVA): 14.7
Maximum power three phase (KW): 35.2
Maximum power three phase (KVA): 44
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400/230
Sockets configuration: 1 x 400V 16A CEE - 1 x 400V 63A CEE - 2 x 230V 16A CEE
Engine: Yanmar 4TNV98T, 4 stroke turbocharged
Emissions Regulations: Stage 5
Engine rpm (rpm): 1500
Starting system: Electric
Engine capacity (cm³): 3319
Number cylinders: 4
Cooling: Water
Alternator: Synchronous
Protection degree: IP23
Motor insulation class: H
Fuel tank capacity (L): 40
Consumption (L/h): 8.1
Running time (h): 4.94
Acoustic power: 97 dB(A)
Acoustic pressure: 72 dB(A) at 7 m
Length (mm): 1640
Width (mm): 770
Height (mm): 1076
Dry weight (Kg): 725
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: Optional
Voltage regulator: AVR
Engine manufacturer: Yanmar

Specific References

Condition New

GENSET MGF 44 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 44 KVA AVR STAGE V

The GENSET MGF 44 Y is a three-phase 44 KVA diesel genset designed to provide reliable and quiet power in a wide range of applications.

Main features:

Maximum three-phase power: 44 KVA (35.2 kW)

Single-phase maximum power: 14.7 KVA (11.76 kW)

Yanmar 4TNV98T (STAGE 0) engine: Reliable, high-performance, liquid-cooled 4-cylinder diesel engine complying with STAGE 0 emission standards.

Electric start: Quick and easy starting with key.

Efficient consumption: Low fuel consumption (8.1 Lt/h) for optimum range.

Super silent: Soundproof design for silent operation (AVR).

Robust construction: Compact and robust design for easy transport and storage.

Technical specifications GENSET MGF 44 Y STAGE V:

Fuel: Diesel
Voltage: 400 V - 230 V
Frequency: 50 Hz
Dimensions:
Length: 1640 mm
Width: 770 mm
Height: 1076 mm
Tank: 40 l
Weight: 725 Kg

If you are looking for a product similar to GENSET MGF 44 Y or with similar characteristics click HERE.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
