CGM 45P-C50 WITH AUTOMATIC CONTROL PANEL 45.9KVA Stage Zero

Name: CGM 45P-C50 WITH AUTOMATIC CONTROL PANEL 45.9KVA Stage Zero
Brand: CGM
SKU: CGM 45P-C50 AUTOMATICO
Price: 15829.5 EUR
Availability: InStock

Reference CGM 45P-C50 AUTOMATICO

Phase type: Three-phase
Maximum three-phase power: 39.6 KW / 49.5 KVA
Continuous three-phase power: 36 KW / 45 KVA
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: PERKINS 1103A-33TG1
Engine speed: 1500 rpm
Starting: Electric
Consumption: 5.6 Lt/h at 75% load
Length: 2000 mm
Width: 885 mm
Height: 1335 mm
Weight: 930 Kg
Supersilenced
AVR

List price

25,327.20 € tax incl.

20,760.00 € tax excl.

Discounted Price

15,829.50 € tax incl.

12,975.00 € tax excl.

Shipping from 359.90 € to Italy buy it today.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference CGM 45P-C50 AUTOMATICO

Data sheet

Phase: Three phase
Maximum power three phase (KW): 39.6
Continuous power three phase (KW): 36
Maximum power three phase (KVA): 49.5
Continuous power three phase (KVA): 45
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Engine: PERKINS 1103A-33TG1
Emissions Regulations: Stationary Use
Engine rpm (rpm): 1500
Speed governor: Mechanical
Starting system: Elettrico
Engine capacity (cm³): 3300
Number cylinders: 3
Cooling: Water
Alternator: Brushless
Poles: 4
Protection degree: IP44
Bore x stroke (mm): 105 x 127
Fuel tank capacity (L): 100
Consumption (L/h): 5.6
Running time (h): 17.9 al 75% del carico
Acoustic pressure: 69 dB(A) at 7 m
Length (mm): 2000
Width (mm): 885
Height (mm): 1335
Dry weight (Kg): 930
AVR: Yes
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: Optional
Voltage regulator: AVR
Engine manufacturer: Perkins

Specific References

Condition New

CGM 45P-C50 WITH AUTOMATIC CONTROL PANEL 45.9KVA Stage Zero

CGM 45P-C50 WITH AUTOMATIC CONTROL PANEL is a professional three-phase diesel-powered generator, designed to offer high reliability and continuous performance.

This model, equipped with a PERKINS 1103A-33TG1 engine operating at 1500 rpm, guarantees a maximum power of 39.3 KW (49.5 KVA) and a continuous use power of 36 KW (45 KVA). Its efficiency is confirmed by a consumption of 5.6 Lt/h at 75% load.

The generator is equipped with an electric start system and provides a voltage of 400 V with a frequency of 50 Hz. Among its main features are the AVR (Automatic Voltage Regulation) system, which ensures a stable output voltage, and its super-silenced structure, which also makes it ideal for use in contexts where noise must be reduced.

Weighing 930 kg and measuring 2000 mm (length), 885 mm (width) and 1335 mm (height), the CGM 45P-C50 WITH AUTOMATIC CONTROL PANEL is a robust and complete unit, ready for use.

Technical characteristics of the CGM 45P-C50 generator:

Phase type: Three-phase
Maximum three-phase power: 39.6 KW / 49.5 KVA
Continuous three-phase power: 36 KW / 45 KVA
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: PERKINS 1103A-33TG1
Engine speed: 1500 rpm
Starting: Electric
Consumption: 5.6 Lt/h at 75% of load
Length: 2000 mm
Width: 885 mm
Height: 1335 mm
Weight: 930 kg
Super-silenced
AVR

If you are looking for a product like the CGM 45P-C50 then you can consult the entire range of CGM generators or other types of products in our catalog to find the one that best suits your needs.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
